IET

                                                            MACHINE FEATURES

Constructor

IMCE

Model

RFDA HT1600

Max operating temperature

RT up to 1600 °C

Heating/cooling rate

1-5 °C/min

Operating atmosphere

Air/Inert gas

Sample holder

On high quality Al₂O₃ insulation material or clamped by PtRh wires

Sample length

Up to 160 mm

Dilatometer specifications

- Sample length: 25 - 40 mm

- Sample diameter: 3 - 7 mm

- Measuring range: 5000 μm

- Resolution LVDT: 100 nm

- Resolution temperature: 0,1 °C

- Measuring force: 0,65 - 0,80 N

- Operation mode: Horizontal

- Inert gas flow
